Optitex Supported Operating Systems
The following table lists the various operating systems Optitex supports according to the Optitex version:
| Windows 2000 | Windows XP | Windows Server 2003 | Windows Vista | Windows 7 | Windows 8 | |
| Version 10 |  Service Pack 3 (includes Windows Installer 2.0) recommended. | Service Pack 2 and. Windows Installer 3.0 (included in Service Pack 2) recommended | Service Pack 1 and Windows Installer 3.1 (included in Service Pack 1) recommended | | |  |
| Version 11 | | Service Pack 3 recommended | Service Pack 1 recommended | Service Pack 2 recommended | Service Pack 1 recommended | |
| Version 12 | | Service Pack 3 recommended | | | Service Pack 1 recommended | |
| Version 12.3 | | | | | | |
| Version O/15 | | | | | | |
Notes:
- When User Account Control (UAC) is ON (Both on Public or Private Modes):
The exact location of the files depends on the operating system and whether you have a 32 or 64 bit machine.- Backup Files will be saved in the following location: [C:\Users\UserName\AppData\Local\VirtualStore\Program Files\Optitex\Backup]
- OCC changes (queue and occ.ini file) will be saved in the following location: [C:\Users\UserName\AppData\Local\VirtualStore\Program Files\Optitex\App\Occ]
- SDM Files will be saved in the following location:
[C:\Users\UserName\AppData\Local\VirtualStore\Program Files\Optitex\SDM Files]
- We recommend that prior to installing Optitex, Windows User Account Control (UAC) should be disabled.
- We recommend to activate and test your network key on a non-server station before hosting the key on a Windows Server environment
- Version 12 is officially not supported on Windows XP 32 bit.
- Windows XP 64 bit operating systems are not supported by any version of Optitex.
- Nest ++ Pro Multicore released with version 12.2 cannot run on Windows XP, use Windows 7 or later.
- If you do not have Windows Installer 3.0 or later installed you may get an ‘Error 1723’ message during the installation, in which case it is recommended to install Windows Installer 3.1
Optitex System Requirements
To run Optitex successfully on your computer, make sure you have the recommended requirements.
2D
Minimum System Requirements
- Processor: Intel Core I3 (or AMD equivalent
- Installed memory (RAM): 2GB
- System type: 32-Bit
- Hard disk: a combination of 1000GB/7200RPM or bigger with 240 GB SSD (OS is installed on the SSD drive )
- VGA card: Standard
- Monitor: 19 inch color
- Drive: Optical DVD/DVDRW (for software installation and backup)
- USB: 1 port (for dongle connection)
- Extra port: USB, LPT or COM ports (for any extra hardware such as Plotter, Digitizer)
- Mouse: Microsoft Compatible Scroll Mouse
- Keyboard: Standard
- O/S: Windows 7
Recommended System Requirements
- Processor: Intel i7-800 Desktop Processor Series or better
- Recommended processor for Nest++ Pro software: Intel i7-3970X or i7-3960X
- Recommended mother board: Gigabyte GA-X99-UD4 or similar, support DDR4 and fit for i7 Processors
- Installed memory (RAM): 2GB
- System type: 32-Bit
- Hard disk: a combination of 1000GB/7200RPM or bigger with 240 GB SSD (OS is installed on the SSD drive )
- VGA card: Standard
- Monitor: 19 inch color
- Drive: Optical DVD/DVDRW (for software installation and backup)
- USB: 1 port (for dongle connection)
- Extra port: USB, LPT or COM ports (for any extra hardware such as Plotter, Digitizer)
- Mouse: Microsoft Compatible Scroll Mouse
- Keyboard: Standard
- O/S: Windows 7
3D
Recommended System Requirements
- Processor: Intel i7-800 Desktop Processor Series or better
- Mother Board: Gigabyte GA-X99-UD4 or similar, support DDR4 and fit for i7 Processors
- Recommended mother board: Gigabyte GA-X99-UD4 or similar, support DDR4 and fit for i7 Processors
- Installed memory (RAM): 16GB or better (DDR3 1333Mhz or better)
- System type: 64-Bit
- Hard disk: a combination of 1000GB/7200RPM or bigger with 240 GB SSD (OS is installed on the SSD drive )
- Hardware Graphic Card: NVIDIA Fermi Architecture GPU (2GB VRAM or better)
- GeForce GTX 560 (2GB VRAM), GT 640, GTX 660 or better
- Quadro 2000 or better
- Monitor: 24 inch color or larger
- Drive: Optical DVD/DVDRW (for software installation and backup)
- USB: 2 ports (for dongle connection)
- Extra port: USB, LPT or COM ports (for any extra hardware such as Plotter, Digitizer)
- Mouse: Microsoft Compatible Scroll Mouse
- Keyboard: Standard
- O/S: Windows 7
Runway Viewer
Minimum System Requirements
- Processor: Intel Core I5 / I7 2nd generation or better.
- Installed memory (RAM): 8GB or better (DDR3 1333Mhz or better)
- System type: 64-Bit
- Hard disk: 500GB / 7200RPM SATA or better. (installation requires approx. 500MB)
- Hardware Graphic Card: NVIDIA Fermi Architecture GPU (2GB VRAM or better)
- GeForce GTX 560 (2GB VRAM), GT 640, GTX 660 or better
- Quadro 2000 or better
- O/S: Windows 7
Note:
- Any configuration that is stronger than specified here, is suitable.
- Optitex is not suggesting any particular brand over the other, as long as it passes the requirements specified.
- Please make sure to visit this page prior to installing new versions to view updated requirements.
